HPE ProLiant DL20 Generation9 (Gen9)

HPE ProLiant DL20 (Gen9)

The dense and compact HPE ProLiant DL20 Gen9 Server powered by Intel® Pentium®, Core i3 and E3-1200 v5 processors provides a unique blend of enterprise-class capabilities at a great value - making it an ideal rack server platform for growing businesses and service providers.

It offers outstanding configuration flexibility to cater to a wide variety of business requirements at an affordable price point. The HPE ProLiant DL20 Gen9 Server offers a range of Hewlett Packard Enterprise qualified options to fit most needs - like affordable drives for light workloads or solid state drives for the demanding requirements; from a single non-hot plug power supply to an efficient HPE Hot Plug Redundant Power Supply; from multiple storage controllers to the HPE FlexibleLOM networking cards - helping customers find the right configuration for their workloads.

What's new

• New LFF hard disk drives with up to 10 TB increases storage capacity to 20 TB.
• Microsoft® Windows® 2016 support.
• The HPE ProLiant DL20 Gen9 server is now Docker ready.
• NVIDIA M2000 GPU support included for graphics intensive workload.

---

Technical Specifications:

Processor family

• Intel® Xeon® E3-1200 v5 product family
• Intel® Core i3
• Intel® Pentium®

Number of processors

• 1

Processor core available

• 4 or 2

Processor cache

• 8MB L3
• 3MB L3

Processor speed

• 3.8GHz

Form factor (fully configured)

• 1U

Form factor chassis

• Rack

Power supply type

• (2) Entry-Level

Expansion slots

• (2) Maximum - For detail descriptions reference the QuickSpecs

Memory, maximum

• 64GB

Memory slots

• 4 DIMM slots
• Maximum

Memory protection features

• Advanced ECC

Drive description

• (2) LFF SAS/SATA/SSD or
• (4) SFF SAS/SATA/SSD
• Hot plug and/or Non-hot plug, depending on model

System fan features

• Non-hot plug non-redundant

Graphic card

• NVIDIA K2200

Network controller

• 1Gb 332i Ethernet Adapter 2 Ports per controller
• Applicable to all models

Storage controller

• Dynamic Smart Array B140i or
• H240 Host Bus Adapter or
• Smart Array P440
• Depending on model

Infrastructure management

• iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials(optional), iLO Scale-Out(optional) iLO Advanced (optional)

Warranty

• 1/1/1 Server Warranty includes one year of parts, one year of labor, one year of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: www.hpe.com/services/support. Additional Hewlett Packard Enterprise support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to www.hpe.com/services/support
